Leeds/GB, Cathedral

1904 Norman & Beard
2010, IV/49, elektr./elektr.



I. NAVE GREAT C-a3


Double Open Diapason 1904 16'
Open Diapason I 1904 8'
Open Diapason II 1904 8'
Hohl Flute 1904 8'
Principal 1904 4'
Harmonic Flute 1904 4'
Fifteenth 1904 2'
Mixture III 1904 2'
Trumpet 1904 8'

II. CHORAL GREAT C-a3


Open Diapason

2010

8'
Bourdon 2010 8'
Dulciana 1904 8'
Principal 2010 4'
Flute 2010 4'
Gemshorn 2010 2'
Cornettino III 2010 2 2/3'

III. CHORAL SWELL C-a3


Rohr Flute 1904 8'
Salicional 1904 8'
Viole Céleste 2010 8'
Principal 2010 4'
Flauto Traverso 1904 4'
Mixture III 2010 1 1/3'
Cornopean 2010 8'
Oboe d'Amour 2010 8'
Tremulant
Sub Octave
Super Octave
Unison Off

IV. NAVE SWELL C-a3


Bourdon 1904 16'
Geigen Principal 1904 8'
Lieblich Gedeckt 1904 8'
Gamba 1904 8'
Voix Céleste 1904 8'
Gemshorn 1904 4'
Lieblich Flöte 1904 4'
Mixture III 1904 2'
Double Trumpet 1904 16'
Horn 1904 8'
Oboe 1904 8'
Vox Humana 1904 8'
Tremulant
Sub Octave
Super Octave
Unison Off

IV. NAVE SOLO C-a3


Tuba 1963 8'
Octave Tuba 1963 4'
Solo Flute 2010 8'
Clarinet 1904 8'

CHORAL PEDAL C-f1


Sub Bass 2010 16'

NAVE PEDAL C-f1


Harmonic Bass 1904 32'
Open Diapason 1904 16'
Violone 1904 16'
Bourdon 1904 16'
Quint Bass 2010 10 2/3'
Octave 1904 8'
Bass Flute 1904 8'
Trombone 1904 16'

COUPLERS


Choral Great to Nave Great
Nave Great to Choral Great
Choral Swell to II
Choral Swell to I
Choral Swell to Nave Swell
Nave Swell to I
Nave Swell to II
Solo to I
Solo to II
Solo to III
Nave Great to Pedal
Choral Great to Pedal
Choral Swell to Pedal
Nave Swell to Pedal
Solo to Pedal

SPECIALS


Nave Great & Pedal Pistons combined
Choral Great & Pedal Pistons combined
Generals on Swell Toes
Swells on III
Exchange Swells
Exchange Greats
